Specification:Placement on Vehicle: Front, Rear,Left, Right

For F-150 2007-2016; For Fusion 2008-2016;

For F-250 F-350 F-450 F-550 Super Duty 2008-2016

For E-150 E-250 E-350 E-450 Econoline Vans 2008-2016

For Lincoln Town Car 2008-2011; For Lincoln Mark LT 2007-2008

For Mustang 2007-2016

For Taurus 2008-2016

For Ranger 2006-2011

For Crown Victoria 2008-2011

For Transit Connect 2011-2016

For Mercury Mountaineer 2006-2010; For Mercury Monterey 2006-2010; For Mercury Mariner 2006-2011

For Edge 2007-2014; For Escape 2006-2016; For Expedition 2008-2016; For Explorer 2006-2016

For Flex 2008-2015; For Fiesta 2008-2016; For Fiesta 2008-2016; For Fiesta 2008-2016; For Focus 2008-2016

For Lincoln MKX 2007-2016; For Lincoln MKT 2007-2016; For Lincoln MKZ 2008-2016; For Lincoln MKS 2008-2016; For Lincoln Navigator 2008-2016

And more...

note: VXDAS TPMS19 does not depend on the car model, but on the car's sensor, so it can support the latest 2024 models

  For F-150 series vehicles

  1. Put the key in and hit the brake（Make the gear in P position）

  2. Ignition switch to OFF, press and release the brake pedal.

  3. Turn ignition switch from OFF position to RUN position 3 times and end at RUN position.

  4. Depress and release the brake pedal.

  5. Ignition to OFF position.

  6. Ignition goes from OFF position to RUN position 3 times and ends at RUN position.

  7. Horn will ring once and TPMS indicator flashes, then learning mode has been entered successfully. If equipped, the message center will display the front left (LF) tire.

How to use VXDAS TPMS19

Step 1 - Set the car in TPMS learning mode. (car horns twice)
Set the gearshift lever to "P"; Put the ignition switch to “ON”: Enter the interface of tire pressure display by DIC: DIC shows "Press Set / Ctrl to re-learn" : Press “Set / Ctrl”
The turn signal is lighted for 3 seconds and the horn beep sound twice to enter the learning mode

Step 2 - Read tire pressure sensor information
Starting relearn process from left front tire, point antenna on correct position. Press & release power button. Once the speaker chirped, move to the next tire.

• 【Widely 】TPMS relearn Tool works on most vehicles after 2005 which equiped with original tire pressure monitoring system manufactured for the North American market.Compatible with Lincoln, Mercury, Mazda,F150, F250, Focus,Fusion...etc
• 【Easy to Use】Super TPMS19 TPMS activation tool with ease, faster operation, activates the in dividual TPMS sensors by pressing one button
• 【REPLACEMENT FOR P/N】8C2Z1A203A, 8C2Z-1A203-A,TPMS19 Car/SUV/Pickup/Light truck.
• 【ESSENTIAL TPMS TOOL】Perfect to monitor tire pressure, training sensors of your cars so the TPMS warning light will not illuminate,a essential tool of replacement tire pressure sensor, tire pressure alarm remove or exchange tires.
• 【SERVICE】Professional Support CE and FCC approved,battery life up to 5 years with normal use
