G-M Tech 2 Scan Tool with CANDI TIS Works for G-M/ SAA-B/ OPE-L/ SUZUK-I/ ISUZ-U/ Holde-n. Tech 2 Scanner supports diagnostic and programming functions with TIS2000 Software.

What is G-M Tech 2 scanner?

G-M Tech 2 scanner with TIS2000 CD is a diagnostic and programming tool for all G-M systems from year 1992 to 2014. Multi-languages Tech II hand-held scan tool supports both OBD I and OBD II vehicles and software can be updated via a 32MB Card.

Tech 2 Scanner is a powerful, versatile hand-held diagnostic computer, designed to help diagnose and repair today’s automotive electronic systems. The Tech 2 supports the changes in the on-board electronic systems for model years 1996 and beyond. With the addition of the CAN Diagnostic Interface (CANdi) module, Tech 2 will support G-M on-board electronic systems for years to come.

The CANDI is an in-cable module that works with existing Tech 2 components including the VCI, cables and adapters to add CAN diagnostic capability to the Tech 2 tester. The CANdi module is fully backward compatible with current Tech 2 functionality and operates transparently when diagnosing non-CAN-equipped vehicles.

Top 5 Reasons To Get Tech 2 Scanner For G-M:

1. Support Car Models: G-M, SAAB, Opel, Suzuki, Isuzu, Holden (from 1992 to 2013)

Note: Tech2 interface only work on 12V cars, no trucks available.

2. When diagnosing, G-M Tech2 main unit doesn't need to connect with computer.

3. You are only available to choose one software card as default in this package, if you need more, you can buy additional G-M Tech2 32MB Memory card.

4. Year Coverage of Diagnosis: From 1992 to 2013. with help of Tis2000 software, it Can Do Programming for Cars Before Year 2007

5. Update via 32MB Card, you are offered to buy the newest update card alone

G-M Tech 2 Scanner Software Version:

For G-M

G-M - English 33.004 1991-2014
G-M - Spanish 33.002 1991-2014
G-M - Germany 32.007 1991-2013
G-M - Japanese 33.002 1991-2013
G-M - French 32.007 1991-2013
G-M - Italiana 32.007 1991-2013
G-M - Portuguese 32.007 1991-2013
G-M - Korean 32.002 1991-2013
G-M - China 33.003 1999-2013

For OPEL

OPEL - English Newly Update to V180 1997-2014
OPEL - Italian Newly Update to V180 1997-2014
OPEL - Polski Newly Update to V180 1997-2014
OPEL - German Newly Update to V85.001 1997-2008
OPEL - Spanish Newly Update to V91.001 1997-2009

G-M Tech2 Card Opel Software Update to V180 Support Cars from the Year 1997 to 2014

For SUZUKI

SUZUKI - English V01.210.020

For SAAB

SAAB - English V148.000

For ISUZU

ISUZU - English CAN-BUS V180 2006-2015 (CAN-BUS support car models after 2010)
ISUZU - English K-Line V11.680 1996-2014 (K-line support car models from 1996 to 2014)

For Holden

Holden - English　 V149.000 1999-2013 (For North American Area Only)
Holden - English V147.000 1999-2012 (For Australia)

Note: TIS2000 software link, software only can work with XP system, it can not work with window 7, window 8, or window 10 system:

https://mega.nz/file/tP1XTI5b#bkpEXi9jtf0KnnbspOeEK31fnlVGpY-4XRthB3EHORE

Why To Get VXDAS Tech 2 Scanner For G-M ?

【Support Car Models】G-M, SAAB, Opel, Suzuki, Isuzu, Holden from 1992 to 2013.

【Update Available】Update via 32MB card, you can buy new card to update.

【Warranty】One Year Warranty with Free Technical Support.

G-M Tech 2 Scanner Features:

1. Authentic G-M software in the Tech 2 Flash means the most comprehensive diagnostic software available for late-model G-M vehicles.
2. Support for on-board diagnostics on all G-M systems from 1994 to 2014.
3. Removable hardware modules provide insurance against scan tool obsolescence.
4. Large, easy-to-read backlit screen.
5. RS232 & RS485 ports provide the avenue to connect future devices to your Tech 2 Flash.
6. Ability to capture stored DTCs, Freeze Frame, and Failure Records for later review.
7. Ability to view the status of vehicle diagnostic tests as they run.
8. Bi-directional The authentic G-M 1992-current year software will provide full bi-directional control when performing power train, chassis, and body diagnostics.

An industry change in protocol from OBD II to Controller Area Network (CAN) has begun.

In order to perform diagnostics on a vehicle that uses the CAN interface; you will need the Tech 2 Flash and a CAN diagnostic interface module. The module connects the Tech 2 Flash diagnostic link cable and the OBD adapter.

Once the module is connected,it can be used on all G-M vehicle applications, even those vehicles using other platforms such as OBD I and OBD II.

The Following G-M Vehicles Utilize The CAN Interface

05 Buick Allure (3.6L)
05 Buick LaCrosse (3.6L)
05 Buick Rainier (5.3L)
04-05 Buick Rendezvous (3.6L)
04-05 Cadillac CTS (3.6L)
04-05 Cadillac SRX (3.6L / 4.6L)
04-06 Cadillac XLR (4.6L)
05 Cadillac STS (3.6L / 4.6L)
05 Chevrolet Cobalt (2.2L)
05 Chevrolet Corvette (6.0L)
05 Chevrolet Equinox (3.4L)
05 Chevrolet TrailBlazer (5.3L)
05 Chevrolet SSR (6.0L)
04 Chevrolet Malibu (Body/Chassis only)
05 Chevrolet Malibu (3.5L)
05 GMC Envoy (5.3L)
05 Pontiac G6 (3.5L)
05 Pontiac GTO (6.0L)
05 Pontiac Pursuit (2.2L)

Vetronix Tech 2 Specifications

1. Dimensions: 12

2. Microprocessor: 32 bit, 16 MHz

3. Memory: 32 MB flash type II PCMCIA. Type III slot available for future expansion.

4. Communications: Integral RS232 communication port.

5. Screen: 3.8x8 backlit monochrome with full graphics capability:320x40 pixels

Displays up to 9 vehicle parameters at once.

Download Tech2 Brochure (5.2 Mb)

Difference between tech 2 and MDI：

Content	For GM Tech 2	For GM MDI
Language	For GM-English, German, Spanish , Japanese, French, Thai , Portuguese, Korean SAAB-English OPEL-English, Italian , German,Spanish HOLDEN-English SUZUKI-English ISUZU-English	Multi-language: English, French, German, Japanese, Italian and so on. Total 30 languages to choose.
Update	Via 32MB Software Card	can not update
Activation	no need active	yes
Advantage	cannot plug original software card, but can support original program	can support software from original factory
OS requirement	no need connect to the PC	Win XP only
Internet connection	no need connect to the PC	can not connect to the internet then install the software, because once connect internet, it will remind you update the software
Support Car Model	Cannot support truck, only for cars, Support all GM systems 1992 thru current year. such as GM/ SAAB/ OPEL/ SUZUKI/ ISUZU/HOLDEN	MDI can test all GM car from 1990-2019year.9
Support programing	support reprogramming, but need to use with TIS2000 together	support offline program,such as chevrolet,opel, but not for all cars

Tech 2 Scanner For G-M Package Includes:

Tech-2 Flash Tester
32 MB PCMCIA Card with G-M OE Applications
CAN diagnostic interface module(CANdi) and instruction sheet download ( 199.2 kb )
RS232 cable and user`s manual.
RS232-DB9 adapter
DLC Cable, DLC Loopback Adapter
12V Cigarette Lighter Power Cable
SAE 16/19 Adapter
NAO 12/19 Adapter
Battery Power Cable
TIS 2000 CD: TIS2000 software available to choose, but only for G-M, version is 2011.

Attention: Our TIS2000 Software just can be used to do programming for G-M Models.
